Eotech's ClipIR-ELR Mk2 uncooled Extended Range Thermal Clip-On Sight was developed to provide soldiers with an unrivaled day / night advantage in detecting, observing and engaging hostile targets, independent of darkness and common obscurants used for visual concealment.

The ClipIR-ELR Mk2 model can be used either as a Clip-on, or as a stand alone Weapon Sight for Sharpshooter or Sniper Rifles or in any weapon platform up to 50 caliber for targeting and observation. A unibody mechanical design ensures endurance in the harshest environments.

The ClipIR-ELR Mk2 sights incorporate the latest IR sensors, electronics and optical technologies to deliver field-proven performance and reliability. The in-house developed and customer-tailored electronics coupled with an intuitive user interface deliver maximum range performance. User-selectable image enhancement and region-of-interest settings result in an enhanced user experience, while automatic local contrast enhancement delivers superior image quality. The built-in digital compass and inclinometer provide range navigation and target orientation. Modern inter-connectivity options provide agile and customizable integration with a broad range of platforms (ATAK, etc.).

Included in the box:

  • Quick Reference Guide
  • Neoprene Hood
  • Lens Cleaning Kit
  • Protective Case


  • Weapon Compatibility: 5.56/7.62 mm Assault Rifles, Grenade Launchers, 0.50* Sniper/MG
  • Optical Magnification: 1X (Cip-on Sight) 2x (weapon sight mode)
  • Digital Magnification: 2X/4X
  • Field of View: 5.3°
  • Focus range: 10 m to infinity
  • Coatings: Hard Carbon on exposed surfaces and High Efficiency on internal surfaces
  • Spectral Response: 8-14 µm (LWIR)
  • Sensor Size: 640х 480 px
  • Pixel Pitch: 12 pm
  • Reticle Overlay: > 10 saved
  • Digital Magnetic Compass: YES
  • Display Brightness Adjustment: YES
  • Type: OLED. High Brightness
  • Display Color: Black & White or Color
  • Pixels: 1280 × 1024 px
  • Image Video Palettes: Back-Hot, White-Hot, Outline
  • Power Source: 3 AA batteries
  • Battery Operating Life @250C: >8 hours
  • Power Up Time: <35
  • /O Port: External Power, Video Out, USB2. Serial
  • Wi-FI/Bluetooth (optional): YES/YES
  • Image Storage: JPEG, > 1000 snapshots
  • Video Storage: H264, > 2hrs
  • Color: Black
  • Weight: 2.1 pounds
  • Mounting Interface: Picatinny
  • Immersion: 10 m
  • MIL- STD 810G, MIL-STD 461E: Full Characterization



  U.S. Government Export Restriction

This item is restricted for export by the State Department and Department of Commerce. Make sure you understand all ITAR laws. ITAR Information
