L3Harris: AN/PVS-14 (M914A) MNVD Assembly - White Phosphor

The M914A™ monocular is based upon the military nomenclature AN/PVS-14. This monocular is available with improved white phosphor tube technology for greater target detection and recognition. Lowlight and nighttime maneuvers appear more natural in black and white, with added contrast detail in shapes and shadows, providing the operator more visual information for assessment and acquisition. White phosphor offers various shades of intensity between black and white (over black and green), resulting in better contrast and depth perception.

• Gen III Night Vision Image Intensifier Tube

• White Phosphor

• Autogated

• Min. FOM: 2376

Features:

• One of the most versatile night vision systems available

• Offers capabilities of a handheld pocket scope, a right- or left-eye-mounted monocular and a weapon sight when mounted in conjunction with an infrared laser aiming device or other night vision compatible primary optic

• An active projected infrared LED provides short-range illumination allowing such activities as map reading • Self-contained system operating on a single AA battery

• Low-battery indicator in eyepiece

• Variable gain control

• Autogated power supply for improved resolution under highlighted settings

Benefits:

• Hands-free or one-hand operation

• High-light cut-off tube protection

• Mounts available for head, helmet or weapon interfaces

• Compact, lightweight and multi-purpose uses

• U.S. manufactured image intensifier (I2) tube

Standard Equipment:

• Monocular

• Operation manual

• Soft carry case

• Battery

• Demist shield

• Eyeguard

• Sacrificial window

• Lens paper

• Shoulder strap

• Retainer cord

• Head-mount

• Weapon and head/helmet-mount adapters

Characteristics:

• Dimensions: 4.5 in. L x 2.5 in. W x 2.4 in. H

• Weight: 0.77 lb. with battery Battery Type (1) AA battery

• Battery Life: ~ 48 hrs. at 25 °C (77 °F)

• Magnification: 1x (± 3 %)

• Field-Of-View: 40.0° (± 2°)

• Objective Lens: 27 mm (1.1 in. (±0.5 mm))

• Minimum Focus Distance: 9.8 in.

• Eye Relief: 25 mm (1 in.)

• Diopter Adjustment: +2 to -6

• Water Resistant: 1 m for 30 minutes
